HT Instruments HT7051: Precision Digital Multimeter for Electrical Testing and Troubleshooting

Insulation resistance measurement with test voltage up to 5kVDC Measurement range up to 10Tohm FIX mode with test voltage of 100, 250, 500, 1k, 2.5k e 5kVDC ADJUST mode with test voltage selectable from 100 to 5kVDC RAMP mode with selectable duration time and test voltage Selection of 3 type of ramp test Polarization Index (P.I.) measurement Dielectric Absorption Ratio (D.A.R) measurement DC/AC TRMS voltage up to 600V SMOOTH feature for stable measurement results GUARD test lead for surface leakage current compensation MX, MIN limit selectable threshold on measurements Automatic discharging of device under test Fuse protection on power supply LCD display with backlight and bargraph Internal memory for saving results Recall saved results at display RS-232 interface for PC connection Rechargeable internal battery > Each Unit Includes HT 7051 KIT14000 : Set 3 cables with alligator clips 2 cables C7001 : Power cord BORSA2000N : Carrying bag for accessories TOPVIEW : Windows software serial cable C232NG1 ISO9000 calibration certificate User manual
