RIGOL PHA2150: High-Precision Differential Probe for Demanding Measurements

Features and Specifications: RIGOL PHA2150 High Voltage Differential Probe, 50X/500X, 200 MHz, PHA Series Product Overview: The RIGOL PHA2150 is a high-performance differential probe designed for precise measurements in high-voltage applications. With its wide bandwidth of 200 MHz and high voltage range of ±1500 V, it is ideal for testing power electronics, automotive systems, and other high-voltage circuits. Features: High Voltage Range: ±1500 V differential, ±750 V common mode Wide Bandwidth: 200 MHz High Input Impedance: 10 MΩ // 10 pF Low Input Capacitance: 10 pF Selectable Attenuation: 50X/500X Ground Reference Compensation: Ensures accurate measurements even with floating ground Auto Zero Function: Automatically compensates for probe offset Overvoltage Protection: Protects the probe from accidental overloads Compact and Lightweight: Easy to handle and transport Specifications: Voltage Range: ±1500 V differential, ±750 V common mode Bandwidth: 200 MHz Attenuation: 50X/500X Input Impedance: 10 MΩ // 10 pF Input Capacitance: 10 pF Rise Time: 1.75 ns (50X), 3.5 ns (500X) Accuracy: ±2% (50X), ±3% (500X) Dimensions: 150 mm x 70 mm x 30 mm Weight: 250 g What’s in the Box: RIGOL PHA2150 High Voltage Differential Probe Grounding Lead Calibration Certificate User Manual Benefits: Accurate and Reliable Measurements: High voltage range and wide bandwidth ensure precise measurements in demanding applications. Versatile and Convenient: Selectable attenuation and ground reference compensation provide flexibility for various testing scenarios. Safe and Durable: Overvoltage protection and compact design ensure safety and longevity. Enhanced Productivity: Auto zero function and easy-to-use interface streamline the measurement process. Value to the Customer: The RIGOL PHA2150 High Voltage Differential Probe empowers engineers and technicians with the tools they need to confidently and efficiently test high-voltage circuits. Its exceptional performance, versatility, and safety features make it an invaluable asset for any professional involved in power electronics, automotive, or other high-voltage applications.
